When building hybrid Web applications where .NET code interacts with WebView HTML content, one of the sticking points is the event based disconnect between loading a document, and then having to wait for the document to load into the control, and then starting to interact with the document via script code.
While there are events - CoreWebView2.DOMContentLoaded
specifically - using an event handler is not always easy to work into application flow.
It's easy to use the WebView control and just display a Url where you are essentially letting the browser complete the page load asynchronously in the background. Take something even as simple as the following when you want to pre-load some content into the HTML document:
WebView.Source = "http://localhost:5200/MyPage"
// BOOM!
await WebView.ExecuteAsync("alert('Document has loaded.')");
Yeah, dumb example, but you get the idea of what this tries to accomplish: Load a page and pop up an alert box over it when it loads.
But - the above code, simplistic as it is, doesn't work, because the script is executed before the page has completed loading. That code will fail!
It's not very difficult to make this work but it takes a little bit of knowledge about the WebView and how it works and you have to implement events in order to make this work. Here's a rough outline of the code you'd need to make the above code actually work:
string envPath = Path.Combine(Path.GetTempPath(), "WpfSample_WebView");
var environment = await CoreWebView2Environment.CreateAsync(envPath);
await webBrowser.EnsureCoreWebView2Async(environment);
WebView.Source = "http://localhost:5200/MyPage"
WebBrowser.CoreWebView2.DOMContentLoaded += async (s, args) => {
await WebView.ExecuteAsync("alert('Document has loaded.')");
}
Always specify a WebView Environment Folder
Setting up an environment is optional but highly recommended! You'll want to make sure you explicitly specify a WebView Environment folder preferably in a Windows temp location that is application specific.
By default the environment folder is created in a folder below the application's startup root. In installed apps that folder is often non-writable and that will cause application failures due to permissions that you likely won't catch until installed users start complaining of issues. More on this in a minute.
This code is a bit verbose and not easy to remember off the top of your head. Additionally the flow is async and it routes into a single Event handler for DOMContentLoaded()
- if you have many documents and operations that occur you're going to have to differentiate between them as part of the event handler code (ie. if arg.Url.Contains()
checks or similar).
Another problem with the event code is that the code fires completely asynchronously, and it's now up to you to communicate the updated status to your application. In a complex flow that means either setting and checking some sort of state or cancellation token, or... duplicating logic that fires in other places for the 'normal' linear flow that assumes the control is already loaded.
It's not exactly straight forward for anything but fire and forget requests or requests that perform a single fixed task. The problem is that this even logic essentially splits your logic into two separate paths, especially if you're updating content via Javascript without completely reloading the entire page and triggering a new page load in which case the event doesn't fire again.
In this post, I'll discuss a simple, but very useful async WaitForLoaded()
helper method, that makes this easier by allowing you to await
the document load operation which is much easier to work with in linear or timing sensitive workflows.
Making this easier with WebView2Handler.WaitForDocumentLoaded()
The Westwind.WebView component is a behavior class that attaches to a WebView control and provides a number of useful enhancements that are aimed at making using the control easier.
It has many useful features:
- Smart automatic (but optional) WebView Environment creation
- Shared Environment for multiple controls in same application
- JavaScript Interop component
- Easy JS function invocation with parameter encoding
- Easy access to variables and properties
- Various different Navigation modes including forced Refresh
- Simple helper
WaitForDocumentLoaded()
- Checking for Compatible WebView Runtime installs
WaitForDocumentLoaded()
The pertinent feature for this post is WaitForDocumentLoaded()
which lets you wait for the document to be ready to be accessed so you can safely interact with it via script code. As the name suggests this is an async method that waits for the document to be ready and it has an optional timeout that you can specify to abort if for some reason the page fails to load.
You can use Navigate → Wait → Process that makes it much easier to create multiple operations in a linear code manner, as opposed to the having a single event that has to figure out its own page routing.
To use this, first import the Westwind.WebView package into your project:
dotnet add package Westwind.WebView
Then to use it you add a property to your form or control that hosts the WebView control and pass in the WebView control:
// Window or Control level Property
public WebViewHandler WebViewHandler {get; set; }
// Window/Control ctor - do this early on so the WebView is read ASAP
WebViewHandler = new WebViewHandler(WebView);
Then when you're ready to navigate - in your Load()
handler or a button click:
// Note: Handler Method has to be async!
private async void EmojiWindow_Loaded(object sender, RoutedEventArgs e)
{
// here or immediately after instantiation of WVH
WebViewHandler.Navigate("http://localhost:5200/MyPage");
if(!await WebViewHandler.WaitForDocumentLoaded(5000))
throw new ApplicationException("Webpage failed to load in time...");
await WebBrowser.ExecuteScriptAsync("alert('You have arrived')");
}
Note that you can also use the built-in JavaScript Interop helper that allows to call methods on a specified 'base' object - window
by default. So instead of:
await WebBrowser.ExecuteScriptAsync("alert('You have arrived')");
you could use:
await WebViewHandler.JsInterop.Invoke("alert","You have arrived");
The JS Interop object automatically encodes parameters and their types so that they are safe to call Javascript code without having to manually encode strings. You can also subclass the BaseJavaScriptInterop
class and add custom methods that wrap any JS calls that you make for easier isolation of the the Interop code.
There are lots of use cases for the WebViewHandler and you can find out more on the Github page.
How does it work?
I'll show how WaitForDocumentLoadeded
works so you don't have to use the WebViewHandler, but there are a few moving parts and they are already integrated into the WebViewHandler class, so it's an an easy way to use this functionality.
The core method that on WebViewHandler
looks like this (full source on GitHub):
/// <summary>
/// Checks to see if the document has been loaded
/// </summary>
/// <param name="msTimeout">timeout to allow content to load in</param>
/// <returns>true if loaded in time, false if it fails to load in time</returns>
public async Task<bool> WaitForDocumentLoaded(int msTimeout = 5000){
if (IsLoaded)
return true;
if (IsLoadedTaskCompletionSource == null)
IsLoadedTaskCompletionSource = new TaskCompletionSource();
var task = IsLoadedTaskCompletionSource.Task;
if (task == null)
return false;
if (task.IsCompleted)
return true;
var timeoutTask = Task.Delay(msTimeout);
var completedTask = await Task.WhenAny(task, timeoutTask);
return completedTask == task;
}
This code uses a Task Completion source to wait on completion status which occurs when the document loaded event has fired (below). In order to track the timeout code also waits on a Task.Delay()
to check for a timeout. Whenever one of those tasks completes the first task is returned - if the task is the original load check task then the control is loaded and the method returns false. If it's the Delay task, then the request timed out and the method returns false.
As you can see there is an external dependency on a IsLoadedTaskCompletionSource
that is set as part of the control load sequence that the WebViewHandler
intercepts. The handler intercepts the CoreWebView2.DOMContentLoaded
event that was shown by the original manual event syntax.
Here's what these bits look like:
// Event hookup in OnInitAsync()
WebBrowser.CoreWebView2.DOMContentLoaded += OnDomContentLoaded;
// Task Completion source to track async completion
public TaskCompletionSource IsLoadedTaskCompletionSource { get; set; } = new TaskCompletionSource();
// Handler
protected virtual async void OnDomContentLoaded(object sender, CoreWebView2DOMContentLoadedEventArgs e)
{
IsLoaded = true; // unrelated - flag that indicates load completion
if (IsLoadedTaskCompletionSource?.Task is { IsCompleted: false })
IsLoadedTaskCompletionSource?.SetResult(); // complete
}
When this event fires the IsLoadedTaskCompletionSource
completion is set to 'done' if it is set, which then triggers the WaitForDocumentLoaded()
to complete.
The WebView can be used to navigate many times, so there's one more bit that's needed which is resetting the completion status on a new navigation by resetting IsCompleted
and the IsLoadedTaskCompletionSource
:
protected virtual void OnNavigationStarting(object sender, CoreWebView2NavigationStartingEventArgs e)
{
IsLoaded = false;
IsLoadedTaskCompletionSource = new TaskCompletionSource();
}
This allows you to use this functionality multiple times. In keeping with the bad example from earlier 😁.
// here or immediately after instantiation of WVH
WebViewHandler.Navigate("http://localhost:5200/MyPage");
if(!await WebViewHandler.WaitForDocumentLoaded(5000))
throw new ApplicationException("Webpage 1 failed to load in time...");
await WebBrowser.ExecuteScriptAsync("alert('You have arrived')");
WebViewHandler.Navigate("http://localhost:5200/MyPage2");
if(!await WebViewHandler.WaitForDocumentLoaded(5000))
throw new ApplicationException("Webpage 2 failed to load in time...");
await WebBrowser.ExecuteScriptAsync("alert('You have arrived again')");
In the real World
The examples I've shown here are very simplistic and somewhat unrealistic, but there are very useful use cases in applications. Specifically, I'm working on an application right now where I have multiple WebView windows that are loading simultaneously and that need to coordinate and ensure that the content has loaded before I can access the content.
Specifically it's - once again - a markdown editor that gets loaded with content and another window that renders that content. Essentially I'm opening a project file, and load up a topic. The first time this happens a new Editor WebView is created and the editor is loaded up with the content of the underlying topic body by loading content from a file.
But at the same time I do this I also need to:
- Select the topic in the project view
- Show a preview of the topic
The topic previewer relies on a topic being ready and loaded in the editor, but if I don't wait for initial loading that fails and I'd end up with an empty topic rendered. Further there's navigation logic that assigns the topic to the editor and that also doesn't work unless the editor WebView is already loaded.
In that scenario it's very useful to be able to deterministicly wait for the editor WebView to load deep in the bowels of the processing logic:
// load the tab and topic from the editor
var (tab, topic) = kavaUi.Addin.DocMonsterModel.GetDocMonsterTabAndTopic();
if (string.IsNullOrEmpty(renderedHtml))
{
// TODO: Render Doc Monster Topic Here!
if (topic != null)
{
// THIS!!!
if( !await editor.EditorHandler.WaitForLoaded(1000) )
{
await Window.CloseTab(tab);
WindowsNotifications.ShowInAppNotifications("Topic loading Error",
"Couldn't load topic into editor. Please re-select the topic.",
WindowsNotifications.NotificationInAppTypes.Warning);
return;
}
// Now I can safely retrive the content from editor in WebView
topic.Body = await editor.GetMarkdown();
topic.Project.Settings.ActiveRenderMode = HtmlRenderModes.Preview;
topic.TopicState.IsPreview = true;
topic.TopicState.IsToc = false;
renderedHtml = topic.RenderTopicToFile(doc.HtmlRenderFilename, TopicRenderModes.Preview);
Summary
WaitForLoaded()
seems like a really simplistic helper - and it is. But I find this method very useful and end up using it in most of my WebView usage. If you're using Javascript to update content especially this helper method is very useful to have handy. In some scenarios like my last example, it's much easier to be able to wait for completion explicitly if and when the WebView is not ready yet.
Obviously it's possible to use the event syntax directly using the DOMContentLoaded
event with event handling, and that's fine for simple rendering scenarios. Using the helper function is mostly useful if you are dealing with Javascript that coordinates with logic in your page and especially with logic that updates loaded page content and only loads a page once (or relatively rarely). In those instances using WaitForLoaded()
provides the ability to use linear logic instead of doubling up code, or having to create some state sharing mechanism explicitly.
WaitForLoaded()
is just one of the useful features of the WebView component and the WebViewHandler
component that makes it easier to interact with dynamic Html content.
